GEBERIT SIGMA 8 WC CISTERN
Intended uses:
For masonry walls
For floor-standing WCs
For single-flush, dual-flush, or flush with flush-stop function
Properties:
Concealed cistern with front actuation
Concealed cistern fully insulated against condensation
Plaster support mesh pre-assembled
Flush bend inserted
Flush bend adjustable 2 cm upwards and 1 cm downwards
Mounting and maintenance work on the concealed cistern without tools
Water supply connection on the top left
Site protection with inspecton opening, can be shortened, suitable for flush plates
< span style='color: #000000;'>Technical data:
Dynamic pressure: 0.1-10 bar
Maximum water temperature: 25 °C
Default flush volume setting: 6 and 3 l
Flush volume, large, adjustment range: 4.5 / 6 / 7.5 l
< div>Flush volume, small, adjustment range: 3-4 l
Scope of delivery:
Water supply connection R 1/2', MF-compatible, with integrated angle stop valve and handwheel
Site protection with inspection opening
< div>Flush bend with EPS foam cups
