Three-phase version

It achieves very high heating efficiency levels, up to 5 COP.

Its integrated structure, which includes all hydraulic components, allows for easy installation, with savings on associated costs.

It uses R32, a refrigerant with low global warming impact and no effect on the ozone layer, characterized by high energy efficiency and a 30% reduced charge compared to R410A.

The two-stage compressor, thanks to its special technology, guarantees exceptional performance over a very wide operating range.

The outdoor temperature range is indeed from -25°C to ~+35°C for Heating, from +10 to +48°C for Cooling, and from -25°C to +45°C for domestic hot water production.

The water outlet temperature range is 25 ~ 65°C: this allows the use of this heat pump with radiant floors, with hydronic terminals, and with medium-temperature radiators.

The DC brushless axial fans are designed for aerodynamic optimization: they guarantee a low noise level, but high efficiency and a large air flow.

The heat exchangers are equipped with a special Anti-Corrosive treatment: the fins, made

Aluminum-Manganese, they are covered with a special layer of epoxy resin, with a typical golden color and another hydrophilic layer.

All main hydraulic components are integrated inside.

Inverter pump

Plate exchanger

Expansion tank

Safety valve

Flow Switch

Water filter supplied (mandatory installation)

Settings are made via a multifunction touchscreen control panel, which allows you to manage:

A 2-way valve (not supplied) to close part of the system

Weekly programming by time slots

Automatic restart after a power failure

Emergency operation (can activate an alternative heat source)

Rapid hot water heating function

Climate control (weather-dependent mode)

Silent function for quiet operation, programmable with timer

Condensation control

Legionella anti-cycle activation: heating the entire tank weekly to a certain temperature (max 70°C) helps eradicate the bacteria responsible for the infection
