Technical Information

• Basic
• Wi-Fi:

  Yes

• Cooling capacity (Min./Nom./Max):

  0.8 / 2.5 / 3.5 kW

• Heating capacity (Min./Nom./Max):

  0.9 / 3.2 / 6.2 kW

• Power consumption - cooling (Min./Nom./Max):

  - / 0.58 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 0.76 / - kW

• Capacity (BTU):

  9000 BTU

• Seasonal cooling efficiency SEER:

  8.6

• SCOP:

  4.6

• Annual energy consumption (Cooling/Heating):

  101 / 973 kWh

• Energy label (Cooling / Heating) - Average climate:

  A+++ / A++

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  -25 ~ 24 °C

• Warranty:

  36 months

• Power input - 50Hz:

  17 kW

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 220 to 240

• Indoor unit
• Size:

  280 x 838 x 229 H x L x D (mm)

• Weight:

  10 kg

• Sound pressure - cooling (high/rated/low/silent):

  46 / 41 / 36 / 19 dB

• Sound pressure - heating (high/rated/low/silent):

  49 / 46 / 39 / 19 dB

• Outdoor unit
• Size:

  550 x 800 x 285 H x L x D (mm)

• Weight:

  34 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 9.52 mm (1/4" / 3/8") mm / inch

• Sound Pressure - cooling (High/Nom./Low/Silent):

  46 / - / - / - dB

• Sound pressure - heating (high/rated/low/silent):

  49 / - / - / - dB

• Basic
• Capacity (BTU):

  9000 BTU

• Transport packaging - MITSUBISHI NINJA MSZ-FT25VGK INDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  30 x 86 x 25; Weight: 12 kg.

• Transport packaging - MITSUBISHI NINJA MUZ-FT25VGHZ OUTDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  57 x 82 x 30; Weight: 38 kg.
