Technical information

• Basic
• Wi-Fi:

  Yes

• Cooling capacity (Min./Nom./Max):

  1.2 / 2.5 / 3.4 kW

• Heating capacity (Min./Nom./Max):

  1.1 / 3.2 / 4.2 kW

• Power consumption - cooling (Min./Nom./Max):

  - / 0.545 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 0.7 / - kW

• Capacity (BTU):

  9000 BTU

• Seasonal cooling efficiency SEER:

  8.5

• SCOP:

  4.7

• Annual energy consumption (Cooling/Heating):

  103 / 716 kWh

• Energy label (Cooling / Heating) - Average climate:

  А+++ / А++

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  - 15 ~ 24 °C

• Suitable for rooms up to:

  20 square meters

• Warranty:

  36 months

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 220 to 240

• Indoor unit
• Size:

  299 x 895 x 195 H x W x L (mm)

• Weight:

  11.5 kg

• Sound pressure - cooling (high/rated/low/silent):

  36 / 29 / 23 / 21 dB

• Sound pressure - heating (high/rated/low/silent):

  37 / 29 / 24 / 21 dB

• Outdoor unit
• Compressor type:

  Mitsubishi

• Size:

  550 x 800 x 285 H x W x L (mm)

• Weight:

  30 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 9.52 mm (1/4" / 3/8") mm / inch

• Sound pressure - cooling (high/rated/low/silent):

  < 47 dB

• Sound pressure - heating (high/rated/low/silent):

  < 49 dB

• Basic
• Capacity (BTU):

  9000 BTU

• Shipping package - MITSUBISHI MSZ-EF25VGKW INDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  30.4 x 89 x 20; Weight: 14.5 kg.

• Shipping package - MITSUBISHI MUZ-EF25VG OUTDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  60 x 80.5 x 30; Weight: 36 kg.
