Features:

• Eco-friendly R32 refrigerant
• Ducted units controllable via KNX, EnOcean and Modbus. Eco mode for 20% energy savings. Compact indoor units (only 200mm high). Weekly programmable timer, with possibility to program 42 events per week. Simplified control system for detecting any malfunctions/faults
• Drain pump included

Technical specifications:

Model:

• Internal catalogue code: CU-Z35UD3EAW
• External catalogue code: CS-Z35UBEA
• Power (BTU): 12,000

Energy efficiency:

• SEER/SCOP (W/W): 5.80/4.10
• Energy efficiency class (cooling): A+
• Energy efficiency class (heating): A+
• Average annual consumption in cooling (kWh/year): 211
• Average annual consumption in heating (kWh/year): 956

Performance:

• Capacity: Nominal cooling (kW): 3.50
• Nominal heating capacity (kW): 3.85
• Internal acoustic pressure (dB-A): 33/27/24 - 35/27/24
• External acoustic pressure (dB-A): 46/47

Electrical data:

• Power supply: 230 V

Characteristics:

• Refrigerant gas: R32
• Guaranteed functional range:
• Cooling °C: -10 ~ +43
• Heating °C: -15 ~ +24

Dimensions:

Internal dimensions H x W x D (mm): 200 x 750 x 640; 19 kg
External dimensions H x W x D (mm): 618 x 824 x 299; 35 kg

Product code: CS-Z35UD3EAW+CU-Z35UBEA
