GREE AIR CONDITIONING TRIAL PULAR 7+7+12
Gree by Argo R32 Refrigerant with very high energy performance
with heat pump - class A++/A+
Main features:
WI FI control - APP FOR iOS and ANDROID SYSTEMS
Satin texture, modern and refined
Appreciable design, minimal style, continuously contemporary, for an even more elegant result, better protection against dust
Delivery of the ;integrated air for easy disassembly
Double flap for precise air flow
Integrated upper air filter, easy to clean even without having to remove it
Very high air flow: air volume increased by 17% in maximum values
Record noise level: at low fan speed, it is 3 dB(A) lower than the value of corresponding traditional products
Optimized air flow in cooling and heating
Model:
-
Series: PULAR
-
9000 Btu Indoor unit model: GWH07AGB-K6DNA1B/I (GREE10156)
-
12,000 Btu Indoor unit model: GWH12AGC-K6DNA1A/I (GREE10150)
-
Outdoor unit model: GWHD(21)NK6OO (GREE10143)
-
Type: Heat pump
-
Power: 6.1 / 6.5 Kw
Energy efficiency:
-
Seasonal efficiency:
SEER / SCOP (average climate): 6.1 / 4.0
Energy efficiency class (cooled): A++
-
Energy efficiency class (heating): A+
-
Seasonal energy consumption kWh/year; 350 - 2,135
Performance:
-
Cooling capacity (kW): 6.1 (2.20-8.30)
-
Heating capacity (kW): 6.5 (3.60-8.50)
-
Outdoor unit air flow m³/h: 3800
-
Outdoor sound pressure (dB(A): 57/58
-
Cooling power consumption kW: 1.48 (0.95 - 2.39)
- Heating power consumption Kw: 1.43 (0.78 - 2.87)
Electrical data:
-
Power (V/Hz/Φ): 230/50/1
Features:
-
Refrigerant gas: R32 - 1.6 Kg / 1.08 T.Co2 eq.
-
Liquid/gas pipe diameter (inches): 1/4" - 3/8"
-
Air flow U.I. 12000 (sa. -a. -m.-b.) m³/h: 550/520/480/400/340/310/280
Air flow U.I. 7000 (sa.-a.-m.-b.) m³/h: 550/ 520/480/400/340/310/280
-
Sound pressure U.I. 7000 (dB(A)): max 40 - min 21
-
Sound pressure U.I. 12000 (dB(A)): max 40 - min 21
- Maximum pipe length with standard charge. m 3-30
-
Maximum pipe length with additional charge: 60 m
-
Maximum height difference (outdoor unit above) m 15
-
Operating limits (outdoor temperature): cooling from -15°c to +43°c / heating from -15°c to +24°c< / span>
-
-
Dimensions and weight:
-
Indoor unit 7000 HxWxD(mm): 260x779x185; 8 Kg without packaging
- Indoor unit 12000 HxWxD(mm): 260x779x185; 8 Kg without packaging
-
Outdoor unit HxWxD(mm): 654x889x340; 47.5 Kg without packaging
GREE by Argo
Product code: PULARWTRIAL7712(21) -
Indoor unit 7000 HxWxD(mm): 260x779x185; 8 Kg without packaging
