Main features:

• WI-FI control - APP FOR iOS and ANDROID SYSTEMS
• Satin texture, modern and refined
• Pleasing design, minimalist style, contemporary without interruption, for an even more elegant result, better dust protection
• Integrated air supply for easy disassembly
• Double flap for precise air distribution
• Integrated superior air filter, easy to clean even without removing it
• Very high airflow: air volume increased by 17% at maximum values
• Record low noise level: at low fan speed, it is 3 dB(A) lower than the value of corresponding traditional products
• Optimized airflow in cooling and heating modes

Model:

• Series: PULAR
• Indoor unit 9000 Btu model: GWH09AGB-K6DNA1B/I (GREE10148)
• Indoor unit 12000 Btu model: GWH12AGC-K6DNA1A/I (GREE10150)
• Outdoor unit model: GWHD(28)NK6OO (GREE10145)
• Type: heat pump
• Power: 8.0 / 9.5 Kw

Energy efficiency:

• Seasonal efficiency:
  • SEER / SCOP (average climate): 6.1 / 4.0
• Energy efficiency class (cooling): A++
• Energy efficiency class (heating): A+
• Seasonal energy consumption kWh/year; 459 – 2520

Performance:

• Cooling capacity (kW): 8.0 (2.30-1.10)
• Heating capacity (kW): 9.50 (3.65-10.25)
• Outdoor airflow m³/h: 3800
• Outdoor sound pressure level (dB(A)): 58
• Power input in cooling kW: 2.12 (1.3 - 3.58)
• Power input in heating Kw: 2.20 (1.0 - 2.87)

Electrical data:
Power supply (V/Hz/Φ): 230/50/1

Features:

• Refrigerant: R32 - 1.8 Kg / 1.215 T.Co2 eq.
• Liquid/gas pipe diameter (inches): 1/4” - 3/8”
• Airflow U.I. 9000 (sa.-a.-m.-b.) m³/h: 550/520/480/400/340/310/280
• Airflow U.I. 12000 (sa.-a.-m.-b.) m³/h: 550/520/480/400/340/310/280
• Sound pressure level U.I. 9000 (dB(A)): max 40 - min 21
• Sound pressure level U.I. 12000 (dB(A)): max 40 - min 21
• Maximum pipe length with standard charge. m 3-40
• Maximum pipe length with additional charge: m 70
• Maximum height difference (outdoor unit above) m 15
• Operating limits (outdoor temperature): cooling from -15°C to +43°C / heating from -15°C to +24°C

Dimensions and weight:

• Indoor unit 9000 HxWxD(mm): 260x779x185; 8 Kg unpackaged
• Indoor unit 12000 HxWxD(mm): 260x779x185; 8 Kg unpackaged
• Outdoor unit HxWxD(mm): 654x889x340; 51 Kg unpackaged

GREE by Argo

Product code: PULARWQUADRI771212(28)
