Helical extractor for direct expulsion to the outside

or into a duct, with diameter adapter kit

for 80-100-120 mm pipes included

T ASPIRANT with TIMER AP3102

• Direct expulsion to the outside and/or into ducts

• Nozzle with extremely low projection

• Wall, ceiling and glass installation with special Aspirkit Vetro

• Diameter adapter kit for 80-100-120 mm pipes included

SERIES

Aspirante series extractors, with a modern and unmistakable design, are easy to install in any type of residential and commercial environment where good flow and pressure performance are required. They are suitable for intermittent or continuous ventilation of small and medium-sized rooms such as bathrooms, kitchens, laundry rooms, offices.

Suitable for installation both for direct expulsion to the outside and for expulsion into a duct.

With the use of Aspirkit Vetro (sold separately), glass installation on the entire Aspirante range is possible.

The reduced size of the rear fitting makes the entire Aspirante series suitable for installation in wall ducts with an initial curve very close to the inlet.

FEATURES

Made of anti-UV and antistatic ABS

Induction motor Insulation class F protected by thermal fuse

Maximum ambient temperature 45°C

Timer adjustable from 45 sec. to 20 min.

Product code: AP3102
