Technical information

• Basic
• Cooling capacity (Min./Nom./Max):

  1.3 / 5.0 / 5.0 kW

• Heating capacity (Min./Nom./Max):

  1.4 / 5.4 / 6.5 kW

• Power consumption - cooling (Min./Nom./Max):

  - / 2.05 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 1.55 / - kW

• Capacity (BTU):

  18,000 BTU

• SEER seasonal cooling efficiency:

  6.5

• SCOP:

  4.3

• Annual energy consumption (Cooling/Heating):

  269 / 1224 kWh

• Energy label (Cooling / Heating) - Average climate:

  A++ / A+

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  -15 ~ 24 °C

• Suitable for rooms up to:

  35 square meters

• Warranty:

  36 months

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 230

• Indoor unit
• Size:

  280 x 838 x 228 H x W x L (mm)

• Weight:

  9 kg

• Sound pressure - cooling (high/nominal/low/silent):

  45 / 40 / 36 / 28 dB

• Sound pressure - heating (high/nominal/low/silent):

  47 / 41 / 34 / 27 dB

• Outdoor unit
• Size:

  550 x 800 x 285 H x W x L (mm)

• Weight:

  35 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 9.52 mm (1/4" / 3/8") mm / inch

• Sound pressure - cooling (high/nominal/low/silent):

  - / 50 / - / - dB

• Sound pressure - heating (high/nominal/low/silent):

  - / 51 / - / - dB

• Basic
• Capacity (BTU):

  18,000 BTU

• Transport package - MITSUBISHI MSZ-HR50VF INDOOR
• Package pieces:

  1 piece

• Package size (HxWxD cm):

  31 x 87 x 25; Weight: 11 kg.;

• Transport package - MITSUBISHI MUZ-HR50VF OUTDOOR
• Package pieces:

  1 piece

• Package size (HxWxD cm):

  58 x 84 x 31; Weight: 38 kg.
