Technical information

• Basic
• Cooling capacity (Min./Nom./Max):

  0.5 / 2.5 / 2.9 kW

• Heating capacity (Min./Nom./Max):

  0.7 / 3.15 / 3.5 kW

• Power consumption - cooling (Min./Nom./Max):

  - / 0.8 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 0.85 / - kW

• Capacity (BTU):

  9000 BTU

• Seasonal cooling efficiency SEER:

  6.2

• SCOP:

  4.3

• Annual energy consumption (Cooling/Heating):

  141 / 614 kWh

• Energy label (Cooling / Heating) - Average climate:

  A++ / A+

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  -15 ~ 24 °C

• Suitable for rooms up to:

  19 square meters

• Warranty:

  36 months

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 230

• Indoor unit
• Size:

  280 x 838 x 228 H x W x D (mm)

• Weight:

  8.5 kg

• Sound pressure - cooling (High/Nominal/Low/Silent):

  43 / 37 / 30 / 21 dB

• Sound pressure - heating (High/Nominal/Low/Silent):

  43 / 37 / 30 / 21 dB

• Outdoor unit
• Size:

  538 x 699 x 249 H x W x D (mm)

• Weight:

  23 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 9.52 mm (1/4" / 3/8") mm / inch

• Sound pressure - cooling (High/Nominal/Low/Silent):

  - / 50 / - / - dB

• Sound pressure - heating (High/Nominal/Low/Silent):

  - / 50 / - / - dB

• Basic
• Capacity (BTU):

  9000 BTU

• Shipping package - MITSUBISHI MSZ-HR25VF INDOOR
• Number of pieces:

  1 piece

• Package size (HхWхD cm):

  31 x 87 x 25; Weight: 10 kg.

• Shipping package - MITSUBISHI MUZ-HR25VF OUTDOOR
• Number of pieces:

  1 piece

• Package size (HхWхD cm):

  57 x 74 x 28; Weight: 26 kg.
