Technical information

• Basic
• Wi-Fi:

  Yes

• Cooling capacity (Min./Nom./Max):

  1.1 / 3.5 / 3.8 kW

• Heating capacity (Min./Nom./Max):

  1.3 / 4.0 / 4.6 kW

• Power consumption - cooling (Min./Nom./Max):

  - / 0.99 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 1.03 / - kW

• Capacity (BTU):

  12,000 BTU

• Seasonal cooling efficiency SEER:

  8.7

• SCOP:

  4.7

• Annual energy consumption (Cooling/Heating):

  141 / 863 kWh

• Energy label (Cooling / Heating) - Average climate:

  A+++ / A++

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  -20 ~ 24 °C

• Suitable for rooms up to:

  25 square meters

• Warranty:

  36 months

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 220 to 240

• Indoor unit
• Size:

  299 x 798 x 245 H x W x D (mm)

• Weight:

  10.5 kg

• Sound pressure - cooling (High/Nom./Low/Silent):

  42 / 30 / 24 / 18 dB

• Sound pressure - heating (High/Nom./Low/Silent):

  45 / 31 / 24 / 18 dB

• Outdoor unit
• Size:

  550 x 800 x 285 H x W x D (mm)

• Weight:

  28.5 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 9.52 mm (1/4" / 3/8") mm / inch

• Sound Pressure - cooling (High/Nom./Low/Silent):

  49 / - / - / - dB

• Sound pressure - heating (High/Nom./Low/Silent):

  50 / - / - / - dB

• Shipping package - MITSUBISHI MSZ-AY35VGK INDOOR
• Number of packages:

  1 piece

• Package size (HxWxD cm):

  87 x 32 x 27; Weight: 12 kg.

• Shipping package - MITSUBISHI MUZ-AY35VG OUTDOOR
• Number of packages:

  1 piece

• Package size (HxWxD cm):
