Technical information

• Basic
• Wi-Fi:

  Yes

• Cooling capacity (Min./Nom./Max):

  2.0 / 7.1 / 8.7 kW

• Heating capacity (Min./Nom./Max):

  2.2 / 8.1 / 10.3 kW

• Energy consumption - cooling (Min./Nom./Max):

  - / 2.01 / - kW

• Power consumption - heating (Min./Nom./Max):

  - / 2.12 / - kW

• Capacity (BTU):

  24 000 BTU

• Seasonal cooling efficiency SEER:

  7.2

• SCOP:

  4.4

• Annual energy consumption (Cooling/Heating):

  345 / 2132 kWh

• Energy label (Cooling / Heating) - Average climate:

  A++ / A+

• Operating range (cooling):

  -10 ~ 46 °C

• Operating range (heating):

  -15 ~ 24 °C

• Suitable for rooms up to:

  50 square meters

• Warranty:

  36 months

• Refrigerant:

  R-32

• Power supply (Phase/Frequency/Voltage):

  1 ~ / 50 / 230

• Indoor unit
• Size:

  325 x 1100 x 257 H x W x D (mm)

• Weight:

  17 kg

• Sound pressure - cooling (High/Nom./Low/Silent):

  45 / 41 / 37 / 30 dB

• Sound pressure - heating (High/Nom./Low/Silent):

  45 / 41 / 37 / 30 dB

• Outdoor unit
• Size:

  880 x 840 x 330 H x W x D (mm)

• Weight:

  55 kg

• Refrigerant piping - Liquid / Gas:

  6.35 / 12.7 mm (1/4" / 1/2") mm / inch

• Sound pressure - cooling (High/Nom./Low/Silent):

  - / 56 / - / - dB

• Sound pressure - heating (High/Nom./Low/Silent):

  - / 55 / - / - dB

• Basic
• Capacity (BTU):

  24 000 BTU

• Transport package - MITSUBISHI MSZ-AP71VGK INDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  36 x 115 x 29; Weight: 20 kg.

• Transport package - MITSUBISHI MUZ-AP71VG OUTDOOR
• Number of packages:

  1 piece

• Package size (HхWхD cm):

  93 x 88 x 37; Weight: 60 kg.
